1st Post, 1st KZ, 1st problem... (starter clutch)
- Randombeat
- Topic Author
- Offline
- User
- 0 to 100 real quick...
Sooooo, I decided on a 1980 kz750H for my first KZ, that i found on craigslist.
Attachment V__6685.jpg not found
Attachment V__D1D9.jpg not found
Attachment V__E2CD.jpg not found
As soon as i saw her, i knew it was the bike for me, and once i drove the 2 hour trip and sat on her, i was in love.
The PO had customized her, a bit, deleted most of the "non essential" bits, and done some paint, and a brat style seat. He hadnt had her running in over a year, but thought that with a plug swap and a good carb clean, she would run.
He was right about that, i changed the plugs, soaked overnight in seafoam after draining the gas, filled up with 100% gas (no ethanol), choked her, and she fired right up....
Ive been without a bike for 4 years, so the sweet sound of those pipes was music to my ears!!!
I hadnt yet tagged her, so i didnt take her out for a ride, i wanted to get her running first....
so the next day, i went to the dmv, registered her, and came back and put on the tag. Went to start her up, and it sounded like the starter wasnt engaging for a bit, then all of a sudden, she fired.
The idle stayed super high, and then when i lowered the idle, she died. upon trying to start her up again, it started sounding like a "can of marbles"...
the PO did tell me that the starter would spin and not catch sometimes, and that he thought it could be the starter, or the starter clutch.
So, i got to wrenching, and removed the starter... hit the start switch, and the starter turned fine....
so i got on good ole google, and began searching... and to my dismay, i found several videos of people reccording starter clutch issues.
so, ive got to replace the starter clutch.
Ive found several used units, but after reading the horror most people have with used or rebuilt starter clutches, i think i want to go with a new one.... enter the "parts obsolete" problem....
so ive found this: www.2wheelpros.com/oem-parts/kawasaki-cl...13193-1062-part.html
can anyone tell me if this is in fact the proper clutch to buy?
also, what else would you replace? starter sprocket? is it the 46 tooth, or the 58 tooth? www.gearhead.com/kawasaki-12046-1032.html#/s/KUS//12046-1032/1 or www.partzilla.com/parts/detail/kawasaki/KP-12046-1072.html ??
Im honestly lost, and i dont want to buy the wrong parts....
i have found a local mechanic that specializes in vintage japanese bikes, whos quoted me 40$ per hour, and will let me sit in and learn about the bike.... (im not mechanically inclined enough to do this myself, and if i started it, and messed up, ill end up spending more...)
so heres my plan:
but a starter clutch, sprocket, race/bearing, oil, filter, gaskets and save up 2-300$ for labor.
Can anyone who has done this recently help me with a parts list?
sorry the post was so long, hopefully someone can help me get this ole girl running again!
1980 KZ750H LTD-- pods-- vance & hines 4-1 --speedo/tach/blinker/switch deletes -- brat style
Please Log in or Create an account to join the conversation.
- 650ed
- Offline
- User
- Posts: 15344
- Thank you received: 2829
Attachment 00003a_2015-03-12.jpg not found
1977 KZ650-C1 Original Owner - Stock (with additional invisible FIAMM horn)
Please Log in or Create an account to join the conversation.
- Randombeat
- Topic Author
- Offline
- User
- 0 to 100 real quick...
- Posts: 274
- Thank you received: 23
1980 KZ750H LTD-- pods-- vance & hines 4-1 --speedo/tach/blinker/switch deletes -- brat style
Please Log in or Create an account to join the conversation.
- daveo
- Offline
- Premium Member
- Posts: 2803
- Thank you received: 655
1982 KZ1100-A2
Please Log in or Create an account to join the conversation.
- Tyrell Corp
- Offline
- User
- "You were made as well as we could make you"
- Posts: 1650
- Thank you received: 261
Can a kicksatarter be retrofitted to a 1980 750 electric start engine?
1980 Gpz550 D1, 1981 GPz550 D1. 1982 GPz750R1. 1983 z1000R R2. all four aces
Please Log in or Create an account to join the conversation.
- DoctoRot
- Offline
- Sustaining Member
- Oh, the usual... I bowl, I drive around...
- Posts: 2559
- Thank you received: 676
Tyrell Corp wrote: It is an expensive job in terms of labour and parts. Read up on some oil threads here :blink: , you might just try changing it and seeing if it helps?
Can a kicksatarter be retrofitted to a 1980 750 electric start engine?
Yes, they share the same cases as the KZ650 and if the cases are split a kick-starter can be installed. a member over at KZ650.info has done it I believe.
My 650 starter clutch is on its last legs so I just kickstart it, I have only tried the button start a handful of times in the year and a half i have owned it. a 650 in good working order is VERY easy to kick start. even stone cold on a 30 degree day I can kick it first try. before i tore my 750E down to rebuild the head, the starter clutch was toast so i would just bump start it, also super easy to do. the funny thing is how it blows peoples minds when they see you do that, haha
Please Log in or Create an account to join the conversation.
- Randombeat
- Topic Author
- Offline
- User
- 0 to 100 real quick...
- Posts: 274
- Thank you received: 23
ive never done that, but might be something that i could do...
1980 KZ750H LTD-- pods-- vance & hines 4-1 --speedo/tach/blinker/switch deletes -- brat style
Please Log in or Create an account to join the conversation.
- 1lanet1864
- Offline
- User
- Posts: 3
- Thank you received: 0
A.Allison
Please Log in or Create an account to join the conversation.
- Hairy dan
- Offline
- User
- Posts: 2
- Thank you received: 0
International Motorcycle Salvage 1-314-385-3334
A World Of Parts At Your Fingertips!
Tell them what you have and what's most important is the tooth count on the sprocket. My flywheel # 21050-1004, punch that number in their search box, it will tell you a lot about the fitment
You can google their nam
Please Log in or Create an account to join the conversation.
- dom2570
- Offline
- User
- Posts: 408
- Thank you received: 27
Whip it like a mule!
Please Log in or Create an account to join the conversation.
- 650ed
- Offline
- User
- Posts: 15344
- Thank you received: 2829
dom2570 wrote: I have an 82 kz750h, I think the starter clutch is going out too. Starter motor is NOS, battery is brand new. Sometimes I'll press the start button and the starter solenoid will click followed by nothing, other I'll hear the starter attempting to turn over and then a click, and then other times it fires right up. Needless to say, I'm getting really good at the bump start!
That does not sound like a starter clutch problem to me. Usually when the starter clutch has a problem it will make a loud noise (like an ooga horn) when it slips. Check all your electrical connections including the ground wire from battery to frame. Ed
1977 KZ650-C1 Original Owner - Stock (with additional invisible FIAMM horn)
Please Log in or Create an account to join the conversation.
- 650ed
- Offline
- User
- Posts: 15344
- Thank you received: 2829
Hairy dan wrote: I just bought the parts you are looking for yesterday from
International Motorcycle Salvage 1-314-385-3334
A World Of Parts At Your Fingertips!
Tell them what you have and what's most important is the tooth count on the sprocket. My flywheel # 21050-1004, punch that number in their search box, it will tell you a lot about the fitment
You can google their nam
If the parts you bought are used, as from a salvage yard, I wouldn't waste my time and energy putting them into the bike. Replacing the starter clutch should be only be done using new parts. Ed
