HollywoodMX's Drouin Supercharged 77 KZ1000!!

More
12 Jul 2013 10:37 #596150 by 531blackbanshee
Replied by 531blackbanshee on topic HollywoodMX's Drouin Supercharged 77 KZ1000!!
okay,
i'm thinkin crazy green highlighted clown face airbrushed in the top of the tank :evil: !







leon

skiatook,oklahoma 1980 z1r,1978 kz 1000 z1r x 3,
1976 kz 900 x 3
i make what i can,and save the rest!

billybiltit.blogspot.com/

www.kzrider.com/forum/5-chassis/325862-triple-tree-custom-work

kzrider.com/forum/5-chassis/294594-frame-bracing?limitstart=0
Attachments:

Please Log in or Create an account to join the conversation.

More
13 Jul 2013 23:42 - 13 Jul 2013 23:49 #596359 by Hollywoodmx
Replied by Hollywoodmx on topic HollywoodMX's Drouin Supercharged 77 KZ1000!!

kzz1king wrote:

Hollywoodmx wrote: I'm not worried at all. After some test breaking... Burn baby burn. The paint won't be there for long. ;)


Is it a high temp paint?
Wayne


The black isnt the green is. But honestlyI have done it before and had zero issues. It's more over-spray then coats of paint. I will prove it when im done the build. :)

531blackbanshee wrote: okay,
i'm thinkin crazy green highlighted clown face airbrushed in the top of the tank :evil: !







leon


Haha! You're crazy!! No way! lol. :lol:

Did have some problems today though. Seat was too wide at the thighs for my liking so back to the fibreglass factory. I sanded the sides down and re-enforced the inside instead. I tested it and I liked it better.

Second discovered issue was I cant get the rear brake to fit in its normal upright spot, it inter fears with the shock mount, I tried to make it work but wasn't successful. Going to have to mount it upside-down with a plate/bracket off the rear axle bolt then to the bigger of the two mount bolts.

Third issue..The sprocket seems to line up to stock sprocket pretty much.. I have no idea how with my previous measurements after flipping the sprocket.. So now I have the D&G set-up as surplus.

- 82 GPz1100injection
- 77 Kz1075 Supercharged
- 81 Yamaha TR-1
- 81 Yamaha xv920
Calgary
Last edit: 13 Jul 2013 23:49 by Hollywoodmx.

Please Log in or Create an account to join the conversation.

More
11 Aug 2013 23:44 #600942 by Hollywoodmx
Replied by Hollywoodmx on topic HollywoodMX's Drouin Supercharged 77 KZ1000!!
I took a break and my free time went to getting my new buell fully setup, riding and I was on holidays. Plus my machinist didn't get to my rear brake adaptor. I was supposed to get 2 weeks off but didn't. hoping to get a week off in Aug to finish it. Did a few things today.


Attachment 20130811_165426.jpg not found



Attachment 20130811_165355.jpg not found


- 82 GPz1100injection
- 77 Kz1075 Supercharged
- 81 Yamaha TR-1
- 81 Yamaha xv920
Calgary
Attachments:

Please Log in or Create an account to join the conversation.

More
12 Aug 2013 10:47 #601002 by 531blackbanshee
Replied by 531blackbanshee on topic HollywoodMX's Drouin Supercharged 77 KZ1000!!
i was wondering about you :laugh: ...

more than usual :P ,

leon

skiatook,oklahoma 1980 z1r,1978 kz 1000 z1r x 3,
1976 kz 900 x 3
i make what i can,and save the rest!

billybiltit.blogspot.com/

www.kzrider.com/forum/5-chassis/325862-triple-tree-custom-work

kzrider.com/forum/5-chassis/294594-frame-bracing?limitstart=0

Please Log in or Create an account to join the conversation.

More
12 Aug 2013 21:21 - 12 Aug 2013 21:24 #601086 by Hollywoodmx
Replied by Hollywoodmx on topic HollywoodMX's Drouin Supercharged 77 KZ1000!!

531blackbanshee wrote: i was wondering about you :laugh: ...

more than usual :P ,

leon


Lol, thanks...I think! (deep down you care..) :lol: :silly:

Well good news is I have that week off now. Starting this friday to the following weekend, its get bike done week!!! :woohoo: Drop your linen and start your grinin!

I will have to take a picture of all the shit I have to install.. :ohmy:

From Aug 19th to 23rd I will hopefully have daily updates of progress. It should move fast.

- 82 GPz1100injection
- 77 Kz1075 Supercharged
- 81 Yamaha TR-1
- 81 Yamaha xv920
Calgary
Last edit: 12 Aug 2013 21:24 by Hollywoodmx.

Please Log in or Create an account to join the conversation.

More
13 Aug 2013 13:16 #601236 by Hollywoodmx
Replied by Hollywoodmx on topic HollywoodMX's Drouin Supercharged 77 KZ1000!!
Ohhh ya. Custom rear brake mount. Some minor cleanup for aesthetics but it's a nice part and fully functional.


Attachment 20130812_193409.jpg not found



Attachment 20130812_194707.jpg not found



Attachment 20130812_205301.jpg not found


- 82 GPz1100injection
- 77 Kz1075 Supercharged
- 81 Yamaha TR-1
- 81 Yamaha xv920
Calgary
Attachments:

Please Log in or Create an account to join the conversation.

More
23 Aug 2013 12:30 #602777 by Hollywoodmx
Replied by Hollywoodmx on topic HollywoodMX's Drouin Supercharged 77 KZ1000!!
Well my progress was hindered by some work, some relaxing, some riding and the enemy....PATIO BEERS!

Attachment 1377207264024.jpg not found



As I have mentioned before the seat is the bane of this builds existence. I needed to build up the sides again due to the lost material from tapering it. Then I had to re-sand the whole thing. :angry: :pinch:

Attachment 20130821_150939.jpg not found




The brake holder needs some slight rework as well. 2 steps forward 1 step back...

Attachment 20130821_162136.jpg not found




I was also having balancing issues with the tires. Research found Metzellers are known for the red dots being off. So after spending hours to get it where it needed less weights (it was needing too many IMO). Next time I find the rims heavy spot without tires on. In the end I gave up and switched to dyna beads instead.. Aint no party like a dynabead party. :cheer:

Attachment 20130821_143804.jpg not found



Attachment 20130821_143848.jpg not found



Attachment 20130821_150956.jpg not found


- 82 GPz1100injection
- 77 Kz1075 Supercharged
- 81 Yamaha TR-1
- 81 Yamaha xv920
Calgary
Attachments:

Please Log in or Create an account to join the conversation.

More
23 Aug 2013 13:45 #602784 by kzz1king
Replied by kzz1king on topic HollywoodMX's Drouin Supercharged 77 KZ1000!!
Keep off the sauce and get to work :laugh: I want to see this in completion. The caliper mount is sweet.
Wayne

74 Z1 1075, 29 smoothbores, owned and ridden since 1976
Home built KZ1000 turbo setup

www.kzrider.com/forum/11-projects/532476...s-budget-turbo-build

www.kzrider.com/forum/11-projects/532489-74-z-makeover

Please Log in or Create an account to join the conversation.

More
23 Aug 2013 15:04 #602794 by DesertKZ
Replied by DesertKZ on topic HollywoodMX's Drouin Supercharged 77 KZ1000!!
I run dynabeads, love'em. Keep it coming!

1979 KZ1000 Shaft
1979 CX500C
1975 GT750 Smoker

Please Log in or Create an account to join the conversation.

More
24 Aug 2013 10:56 #602869 by Bad Kaw
Replied by Bad Kaw on topic HollywoodMX's Drouin Supercharged 77 KZ1000!!
Sweet build.

78 Kawasaki Z1R
81 Kawasaki KZ1000J (mods)
82 Kawasaki ELR Clone (1000 J)
82 Kawasaki KZ750R1/GPz750 ELR-ed
70 Kawasaki KV75
83 Honda CB1100F (few mods)
79 Suzuki GS1000 (rolling frame / project / junk)
84 Suzuki GS1150ES (modified project)
83 Yamaha XJ900R (project / junk)

Please Log in or Create an account to join the conversation.

More
24 Aug 2013 13:21 #602880 by Hollywoodmx
Replied by Hollywoodmx on topic HollywoodMX's Drouin Supercharged 77 KZ1000!!

kzz1king wrote: Keep off the sauce and get to work :laugh: I want to see this in completion. The caliper mount is sweet.
Wayne


I am!! I am!! lol. :cheer:

Lots of progress, 2 part post.

Seat mount all setup and Moto dynamic integrated "sequential" signal led tail light installed. Super sprox sprocket installed.


Attachment 20130823_124956_LLS.jpg not found



Attachment 20130823_122132.jpg not found



Attachment 20130823_122155.jpg not found



Attachment 20130823_125108_LLS.jpg not found



Attachment 20130823_145645.jpg not found



Attachment 20130823_145657.jpg not found


- 82 GPz1100injection
- 77 Kz1075 Supercharged
- 81 Yamaha TR-1
- 81 Yamaha xv920
Calgary
Attachments:

Please Log in or Create an account to join the conversation.

More
24 Aug 2013 13:33 - 24 Aug 2013 13:42 #602882 by Hollywoodmx
Replied by Hollywoodmx on topic HollywoodMX's Drouin Supercharged 77 KZ1000!!
How NOT to install an R1 calipers...I was like wow these cables are short! :blink: I raised the forks in the tree as much as I could but I didn't expect the lines to be that short from that...Umm they were upside down.. :blush: :whistle: :silly:

Attachment 20130823_171840.jpg not found



Attachment 20130823_171846.jpg not found



Install callipers and lines properly! :evil: ..Was a bit of a puzzle a year later. Polished and reinstalled oil cooler. Sits on the kickstand now without the jack. Installed shorty leavers.

Attachment 20130823_192104.jpg not found




Shock mount solution. Re-used old shock mounts rubber and metal collars, just sized them down to make it into a backing plate forcing the shocks out further from the pegs.

Attachment 20130823_192117.jpg not found



Attachment 20130823_195001.jpg not found



Attachment 20130823_195035.jpg not found



So the bike is lower for sure. It feels a lot lighter than the original Z by quite a bit. No doubt the gas tank and seat are making a big difference. The stock forks with all its goodies are pretty heavy and the wheels too. When I had the kickstand on a 2x4 it accidentally fell over to the opposite side and I saved it by only holding the rear wheel and I pushed it back. There is no way I could have done that stock.

I cant help but wonder if some of the lightness comes from the wider tires creating less sharp of a lean pivot as well. Meaning its easier to tip the bike over stock.

- 82 GPz1100injection
- 77 Kz1075 Supercharged
- 81 Yamaha TR-1
- 81 Yamaha xv920
Calgary
Attachments:
Last edit: 24 Aug 2013 13:42 by Hollywoodmx.

Please Log in or Create an account to join the conversation.
