Turning the pollution cap into a crankcase vent
- kzz1king
- Offline
- User
wireman wrote: At the same time like Ive said before if you have to start adding lots of extra venting just to keep oil from blowing out of a motor its time to do a leak down test to make sure youre not just blowing everything past worn rings or a worn bore.
On a high rpm racing engine thats spinning its way down the track at 10,000 rpms its understandable that things getting stirred up internally pretty violently,but on the typical street bike thats just being jumped on once in a while its not such a big issue.
If youve got a streetbike thats blowing gaskets out to vent itself and the stock crankcase vent isnt clogged up youve got internal issues and the extra venting is just a band aid.
I agree. I think turbo applications may be different though, correct?
Wayne
74 Z1 1075, 29 smoothbores, owned and ridden since 1976
Home built KZ1000 turbo setup
www.kzrider.com/forum/11-projects/532476...s-budget-turbo-build
www.kzrider.com/forum/11-projects/532489-74-z-makeover
Please Log in or Create an account to join the conversation.
- wireman
- Offline
- User
- The most interesting prick in the world
- Posts: 4761
- Thank you received: 299
The turbo is force feeding the cumbustion chamber which puts more load on the rings which in turn causes some extra blow by if the rings cant handle it all.kzz1king wrote:
wireman wrote: At the same time like Ive said before if you have to start adding lots of extra venting just to keep oil from blowing out of a motor its time to do a leak down test to make sure youre not just blowing everything past worn rings or a worn bore.
On a high rpm racing engine thats spinning its way down the track at 10,000 rpms its understandable that things getting stirred up internally pretty violently,but on the typical street bike thats just being jumped on once in a while its not such a big issue.
If youve got a streetbike thats blowing gaskets out to vent itself and the stock crankcase vent isnt clogged up youve got internal issues and the extra venting is just a band aid.
I agree. I think turbo applications may be different though, correct?
Wayne
But if it gets to the point where its blowing more past the rings than youre gaining its time to look at differant options as far as the finish on cylinder wall or the rings,Ive got a few sets of pistons laying around from higher end motors that are "gas ported" I believe the term is called where they drill holes in the ring land of the pistons to allow some of the cylinder/combustion pressure to come in behind the rings to force them against the cylinder walls to help them seal better .
It all depends on your situation and motor condition
posting from deep under a non-descript barn in an undisclosed location southwest of Omaha.
Please Log in or Create an account to join the conversation.
- wireman
- Offline
- User
- The most interesting prick in the world
- Posts: 4761
- Thank you received: 299
Whats that across bottem of the cap?kzz1king wrote:
Attachment Picture175.jpg not found
Attachment Picture180.jpg not found
posting from deep under a non-descript barn in an undisclosed location southwest of Omaha.
Please Log in or Create an account to join the conversation.
- kzz1king
- Offline
- User
- Posts: 822
- Thank you received: 52
Wayne
74 Z1 1075, 29 smoothbores, owned and ridden since 1976
Home built KZ1000 turbo setup
www.kzrider.com/forum/11-projects/532476...s-budget-turbo-build
www.kzrider.com/forum/11-projects/532489-74-z-makeover
Please Log in or Create an account to join the conversation.
- wireman
- Offline
- User
- The most interesting prick in the world
- Posts: 4761
- Thank you received: 299
posting from deep under a non-descript barn in an undisclosed location southwest of Omaha.
Please Log in or Create an account to join the conversation.
- donthaveakawman
- Visitor
If you look inside the airbox the oil breather is right underneath the clean air hose for the emissions.Patton wrote:
Am thinking there's no separate venting for the bottom end and top end, because they're connected by the cam chain tunnel between the crankcase and cam area.kzz1king wrote: I thought I already asked this but do not see it. Does additional venting from the bottom end negate having to vent the top end? I Vented through fill plug on mine with no problems.
Wayne
Good Fortune!
Please Log in or Create an account to join the conversation.
- wireman
- Offline
- User
- The most interesting prick in the world
- Posts: 4761
- Thank you received: 299
oopsies! :sick:donthaveakawman wrote:
If you look inside the airbox the oil breather is right underneath the clean air hose for the emissions.Patton wrote:
Am thinking there's no separate venting for the bottom end and top end, because they're connected by the cam chain tunnel between the crankcase and cam area.kzz1king wrote: I thought I already asked this but do not see it. Does additional venting from the bottom end negate having to vent the top end? I Vented through fill plug on mine with no problems.
Wayne
Good Fortune!
posting from deep under a non-descript barn in an undisclosed location southwest of Omaha.
Please Log in or Create an account to join the conversation.
- donthaveakawman
- Visitor
wireman wrote:
The emissions system hoses are pulling unburned fuel vapors from exhuast ports of motor,not venting crankcase pressure in their stock formdonthaveakawman wrote:
If you look inside the airbox the oil breather is right underneath the clean air hose for the emissions.Patton wrote:
Am thinking there's no separate venting for the bottom end and top end, because they're connected by the cam chain tunnel between the crankcase and cam area.kzz1king wrote: I thought I already asked this but do not see it. Does additional venting from the bottom end negate having to vent the top end? I Vented through fill plug on mine with no problems.
Wayne
Good Fortune!
The velocity of the exhaust gasses running through the headers creates a vacuum when the valve closes. then pulls the reed valve to let airbox air in. :pinch:
Please Log in or Create an account to join the conversation.
- kzz1king
- Offline
- User
- Posts: 822
- Thank you received: 52
Some crap I saved for some unknown purpose but I knew I would need it someday. My garage is full of stuff like that! Some sort thin anodized aluminum.wireman wrote: No I mean whats it made of?
Wayne
74 Z1 1075, 29 smoothbores, owned and ridden since 1976
Home built KZ1000 turbo setup
www.kzrider.com/forum/11-projects/532476...s-budget-turbo-build
www.kzrider.com/forum/11-projects/532489-74-z-makeover
Please Log in or Create an account to join the conversation.
- wireman
- Offline
- User
- The most interesting prick in the world
- Posts: 4761
- Thank you received: 299
Yes youre correctdonthaveakawman wrote:
wireman wrote:
The emissions system hoses are pulling unburned fuel vapors from exhuast ports of motor,not venting crankcase pressure in their stock formdonthaveakawman wrote:
If you look inside the airbox the oil breather is right underneath the clean air hose for the emissions.Patton wrote:
Am thinking there's no separate venting for the bottom end and top end, because they're connected by the cam chain tunnel between the crankcase and cam area.kzz1king wrote: I thought I already asked this but do not see it. Does additional venting from the bottom end negate having to vent the top end? I Vented through fill plug on mine with no problems.
Wayne
Good Fortune!
no, the velocity of the exhaust gasses running through the headers creates a vacuum when the valve closes. then pulls the reed valve to let airbox air in. :pinch:
posting from deep under a non-descript barn in an undisclosed location southwest of Omaha.
Please Log in or Create an account to join the conversation.
- donthaveakawman
- Visitor
I just don't understand sometimes :evil: .donthaveakawman wrote:
If you look inside the airbox the oil breather is right underneath the clean air hose for the emissions.Patton wrote:
Am thinking there's no separate venting for the bottom end and top end, because they're connected by the cam chain tunnel between the crankcase and cam area.kzz1king wrote: I thought I was homophobic enough, I already asked this but do not see it. Does additional venting from the bottom end negate having to vent the top end? I Vented through fill plug on mine with no problems.
Wayne
Good Fortune!
Please Log in or Create an account to join the conversation.
- wireman
- Offline
- User
- The most interesting prick in the world
- Posts: 4761
- Thank you received: 299
Attachment 31178510095_R.jpg not found
How about something like this in the header past collector?
