Single Gauge bracket for 1975 Z1B 900

28 May 2015 06:59 - 28 May 2015 07:15
#674159
I got rid of the two stock gauges (they were really bad and unrepairable) and designed a custom single gauge through Speed Hut. The gauge is awesome. I am fabricating a bracket now to house the new 4" gauge. Does anyone else on here have pics or a measurement for a single gauge bracket. I made one in Catia and had a prototype CNC'd but I am not sure I like it and want to get some other ideas. I will post mine soon once I make some changes. The 3D image of it is posted below along with my white faced gauge that just arrived. But if you get a chance, please post a pic or a site of someone who makes a single bracket for the Z1. thanks.

Speedhut Gauge
Pic 2 3D cad file
Last edit: 28 May 2015 07:15 by mardimus.
