Smoke from under the seat. ribbed unit hot
- Johnf41us
- Topic Author
- Offline
- User
Please Log in or Create an account to join the conversation.
- Irish Yobbo
- Offline
- User
- Posts: 380
- Thank you received: 93
That's your regulator-rectifier, the device that converts the three-phase AC voltage from your alternator to ~14V to run your electronics and charge your battery. If you have a generator instead of an alternator, much the same function - it will lower the voltage to about 14V (but no rectification required for a generator).
Luckily when they die they usually just cut out and stop charging. They can get hot in normal use (that's why they're ribbed), but certainly shouldn't smoke. If you're unlucky, it's let too much voltage though, but I've never seen this happen (but I've never dealt with generators,which I think your bike may have).
If it's smoking you'll need another anyway, so get a new one. If it had failed, it won't charge your battery - this might be what stopped the bike. Hopefully it hasn't damaged anything else - I've never seen it happen, but it could. Charge your battery, change out the regulator/rectifier, and start it up again. Get a voltmeter and check the output from the regulator/rectifier. It should be about 14V when the bike is running. Might be a bit lower at low revs, especially if you have lights on.
If you're game to start it up again with the old one still in place, charge the battery, and hook a multimeter across the battery terminals before starting it up. When it starts, check the voltage - shouldn't get any higher than about 14.5V. Hold it at higher revs, and it should do the same thing. If the voltage is no higher than the voltage before you started the bike, it's not working. If it's higher than 14.5V, it's over-charging. Don't keep it running if the voltage is too high. If it's too low, not an issue, it will just drain your battery.
1981 KZ750 LTD
Please Log in or Create an account to join the conversation.
- 650ed
- Offline
- User
- Posts: 15344
- Thank you received: 2829
1977 KZ650-C1 Original Owner - Stock (with additional invisible FIAMM horn)
Please Log in or Create an account to join the conversation.
- SWest
- Offline
- Sustaining Member
- 10 22 2014
- Posts: 22972
- Thank you received: 2749
Steve
Please Log in or Create an account to join the conversation.
- martin_csr
- Offline
- User
- Posts: 8068
- Thank you received: 1656
Please Log in or Create an account to join the conversation.
- SWest
- Offline
- Sustaining Member
- 10 22 2014
- Posts: 22972
- Thank you received: 2749
Steve
Please Log in or Create an account to join the conversation.
- Patton
- Offline
- KZr Legend
- Posts: 18640
- Thank you received: 2098
650ed wrote: . . . buy a Kawasaki Service Manual . . . to understand the different systems on the bike . . . No one has ever regretted buying one. . . .
Here's a reference pic from Ed's old BSA manual :lol:
Good Fortune!
1973 Z1
KZ900 LTD
Please Log in or Create an account to join the conversation.
- SWest
- Offline
- Sustaining Member
- 10 22 2014
- Posts: 22972
- Thank you received: 2749
Now that's funny.
Steve
Please Log in or Create an account to join the conversation.
- MFolks
- Offline
- User
- Posts: 6650
- Thank you received: 540
www.redlinecycle.com/rectifiers.html
1982 GPZ1100 B2
General Dynamics/Convair 1983-1993
GLCM BGM-109 Tomahawk, AGM-129A Advanced Cruise Missile (ACM)
Please Log in or Create an account to join the conversation.
- 650ed
- Offline
- User
- Posts: 15344
- Thank you received: 2829
Patton wrote:
650ed wrote: . . . buy a Kawasaki Service Manual . . . to understand the different systems on the bike . . . No one has ever regretted buying one. . . .
Here's a reference pic from Ed's old BSA manual :lol:
Good Fortune!
:laugh: :laugh: :laugh: :laugh: True! In fact, I sold the BSA because the Genuine Lucas Wiring Harness Smoke was not longer available from the dealer. Without that smoke I never new if the Lucas electrics was working or not.
1977 KZ650-C1 Original Owner - Stock (with additional invisible FIAMM horn)
Please Log in or Create an account to join the conversation.
- SWest
- Offline
- Sustaining Member
- 10 22 2014
- Posts: 22972
- Thank you received: 2749
Steve
Please Log in or Create an account to join the conversation.
- Tyrell Corp
- Offline
- User
- "You were made as well as we could make you"
- Posts: 1650
- Thank you received: 261
1980 Gpz550 D1, 1981 GPz550 D1. 1982 GPz750R1. 1983 z1000R R2. all four aces
