Overflows leaking after jet change

  • Jcmeyer76
  • Jcmeyer76's Avatar Topic Author
  • Offline
  • User
  • Posts: 2
  • Thanks: 0

Overflows leaking after jet change

11 Oct 2020 10:45
#836618
Ok guys have a question I havent been able to find an answer for... I just changed my main jets in my 81 650 and once I got her started back up my overflows canstantly have a stead stream. I've checked the petcock, float levels, overflow tubes, vacuum leaks, float needles, and everything looks good. The only thing different I can think of is that my pilots are still a size too small (had the wrong ones ordered so had to reorder). I've triple checked everything and I had no issues before changing the mains, anyone have any idea what could be the issue or know something that I might have missed?

Please Log in or Create an account to join the conversation.

  • hardrockminer
  • hardrockminer's Avatar
  • Offline
  • Sustaining Member
  • Posts: 2982
  • Thanks: 1087

Re: Overflows leaking after jet change

11 Oct 2020 13:26
#836638
Sometimes a float will stick on the side of the bowl when re-assembled. This could be the cause of your problem.
I have several restored bikes along with a 2006 Goldwing with a sidecar. My wife has a 2019 Suzuki DR 650 for on and off road.
The following user(s) said Thank You: Mikaw

Please Log in or Create an account to join the conversation.

  • Mikaw
  • Mikaw's Avatar
  • Offline
  • Sustaining Member
  • Posts: 4832
  • Thanks: 1849

Re: Overflows leaking after jet change

11 Oct 2020 13:37
#836642
Like HardRockMiner mentioned. You can try tapping on the bowl of the offending carb. Shake the bike right to left... if that doesn’t help your only option is to pull the bowl and find out what happened. Could be a piece of shumoots in the float seat. A Qtip works good to reach up in there and wipe it out. While you have it out look at the float needle for wear.

1976 KZ 900 A4 kzrider.com/forum/11-projects/613548-1976-kz-900-a4
1976 KZ 900 B1 LTD
1978 KZ 1000 B2 LTD
1980 KZ 750 E1
Kowledge Speaks, But Wisdom Listens.
Jimi Hendrix.

Attachments:

Please Log in or Create an account to join the conversation.

  • asphalt900
  • asphalt900's Avatar
  • Offline
  • User
  • Posts: 781
  • Thanks: 335

Re: Overflows leaking after jet change

12 Oct 2020 05:26
#836678
Did you replace the float bowl gaskets? Sometimes the gasket material can be touching the float and this will cause the overflow condition mentioned.
The following user(s) said Thank You: hardrockminer

Please Log in or Create an account to join the conversation.

  • bSzemanKZ440
  • bSzemanKZ440's Avatar
  • Offline
  • User
  • Mechanical Engineering student
  • Posts: 20
  • Thanks: 0

Re: Overflows leaking after jet change

15 Oct 2020 12:33
#836916
I just noticed that, while cleaning my 81 kz650's carbs yesterday the float would randomly get stuck
1980 KZ440-B1
1981 KZ650 CSR

Please Log in or Create an account to join the conversation.

  • Jcmeyer76
  • Jcmeyer76's Avatar Topic Author
  • Offline
  • User
  • Posts: 2
  • Thanks: 0

Re: Overflows leaking after jet change

16 Oct 2020 11:07
#837000
Thanks guys, I'm pretty sure it's a stuck float or something in the seat, I'm out of town now but I'll tear into it when I'm back home and see what I can find
