Testing Z1 crank for twist
- slmjim+Z1BEBE
- Topic Author
- Offline
- User
- Enjoy Life! IT HAS AN EXPIRATION DATE!
We need to check the crank in The Wounded Z for true. Need advice on what & where to buy (or borrow?) a straight & true rod to check a Z1 crank for twist.
Thanks
&
Good Ridin'
slmjim & Z1BEBE
