KZ650 Bonneville Bike Part 2
- KZB2 650
- Topic Author
- Offline
- User
They said since the 141 mph record was a number of changes have been made.......For one they discovered that the 11 3/4 comp used was to high and have since lowered it to 10 3/4 to 1 on all there piston sets, Also that they discovered a few bent valves and have since deepened the valve pockets ..... they also discovered that the 31mm Keihins they were running (Although the article showed them running 29mm smooth bores) were to much carb and recommend the 29mm smoothes as the hot set up.
Dennis says knowing what he knows now and with the changes he said a full 10 mile per hour higher could have been added making it 151mph!!!
In the article they built a 706cc motor, 10 3/4 to one, A degree'd in KR150.420 lift cam (no other specs givin), 29mm SB W/ 50mm velocity stacks, Their ported and polished heads with stock valves, seals and their springs, (flowing 84 cfm) (stock Z1 head they said flows 82, no specs on the stock 650 head), stock cir clips (not teflon buttons) 4380 crome moly pins, HD clutch springs, a Torrington bearing clutch pusher (a must) and stock plates, A Gerex CDI ignition that he swears by, stock lower end, stock cam chain, timing advanced 2 degrees, Their header, Champion N2GYs (N59Gs for racing), A 15T front sprocket and stock HP Z1 valve lifters that were drilled like the RC ones I saw on here. The lifters were mainly were for ease of adjustment and he is working on HD shim unders that will hold up to the 420 lift. No shims were ever spit out though even though the Bonnie bike often saw 13,000 rs.
Although Motorcyclist said it might be a little high ......They (Denco) estimated 103HP at the crank and 90 at the wheel and set the IDBA E modified record at 11.23 at 116 and had since lowered it to 10.73 at 119 with this set up. Motorcyclist turned a 11.8 with it with the stock tire and granny shifting. Why they didn't do a slick and wheelie bar I have no idea...... All that rode the bike said that it was a animal from 7,000 to 11,000 rpm and since it needed to idle at 1,500 to keep it clean and was a little lacking down low...... would still run amazing and be more street able with their KR100 .....352 lift cam.
They also talked of the piston dome having a power notch design that burns cleaner and has better combustion (designed by Dennis and made for them by MTC ) Dennis claimed a 26 HP pick up with these over the stock Z! 900 pistons but didn't go any farther. No info on the 650 increase. Might be a little hype but wanted to report it. At this timethey were selling 695cc pistons, 706cc special order and the 738cc pistons that needed bigger sleeves..... all 10 3/4 only.
Also talked of putting a hollow tube where the oval o ring is on the cylinder (oil passage hole) to keep the o ring in place and leak free. Think the 78s on up solved that.
Dennis said 3 things you can do to a stock 650 to lower the 13.1 et to 12.7 is Put in Premium gas, advance the timing 2 degree's and install thin wired Champion N2G plugs although I did N3G as stock ones call for 4s so these are very cold. I'm sure I didn't see this big of an improvement but it ran crisp and very good. I'm sure I saw this in another article him saying this and adding a 15t front sprocket too but it didn't say this here...... He also said after this on a stock motor do the header ..... then the 29mm smooth bores as the hot set up..... then the bore and cam together.
Well anyway hope you liked the info and hope it was ok to put this under the engine section..... figured more folks would see it.......... if you are a s big a fan of the Bonnie bike and article as I am it would probably be worth it picking this issue up....... have never seen it printed out any where. ..... picked up a little info that wasn't in the Bonnie article...... God I wish Denco was still around ..... imagine what they would be running now. :woohoo:
1978 KZ650 b-2
700cc Wiseco kit 10 to 1.
1980 KZ750 cam, ape springs, stock clutch/ Barnett springs.
Vance and Hines Header w/ comp baffle and Ape pods, Dyna S and green coils, copper wires.
29MM smooth bores W/ 17.5 pilots, 0-6s and 117.5 main
16/42 gearing X ring chain and alum rear JT sprocket.
Please Log in or Create an account to join the conversation.
- pete greek1
- Offline
- User
- Posts: 1510
- Thank you received: 185
www.google.com/url?sa=t&rct=j&q=&esrc=s&...XEEWq6CRjHXhsI06b5tg
Pete
1980 LTD 1000..,1976 LTD 900, have the 1000&900 now. the rest are previous= 1978 KZ 650 B.., 1980 Yamaha XT 500..,1978 Yamaha DT 400.., 1977 Yamaha yz 80..,Honda trail ct 70.., Honda QA 50...5-1/2 hp brigs & straton CAT chopper mini bike...3-1/2 hp mini bike (WHEN GAS WAS ABOUT 45 CENTS A GALLON)!!!!
Please Log in or Create an account to join the conversation.
- Rockranch
- Offline
- User
- Posts: 434
- Thank you received: 23
I remember that article back in the day. One of MANY Kaw articles all throughout those years. Love the denco headers too. They were a top performance booster for 900/1000's also, although not as popular due to their shorter design and low visibility because of the left side exit. I wish I could find one now for one of my current projects. Thanks for the post Pete. Always up for a good reminisce of the bygone good old days of yore!.................................Mikepete greek1 wrote: Another article here with lots of pics.
www.google.com/url?sa=t&rct=j&q=&esrc=s&...XEEWq6CRjHXhsI06b5tg
Pete
Vroom-vroom!!!
(2)-1976 KZ900B-LTD's
1-all stock low mileage...
1 modified
1977 KZ1000 (awaiting resurrection!)
...and an old school Honda CB750 Chopper is next on my bucket list!
Oh...and a Pocket Rocket lol!!!
Please Log in or Create an account to join the conversation.
- missionkz
- Offline
- Sustaining Member
Then on went the Denco 4 into 1 pipes and re-jetted-re-needled carbs, as per what Denco actually told me to try, and it was NOT radical either.
Then also put a 35/15 sprocket combo on.
I had no trouble getting my KZ1000 with stock tires into the high (very high) 11's back in Detroit.
Of course I was in my late 20's and only weighed in at 132lbs back then! LOL
11.68 et was the fasted i ever got that thing.... maybe a fluke but it would run all day at the strip in the very low 12's and I'd ride it there and back home with my girl friend on the back and 43-45mpg.
Those were the days.... and I still have the bike with the same Denco headers and carbs,,, now a 1075cc Wiseco kit, stock carbs same 35/15 sprocket setup.
Bruce
1977 KZ1000A1
2016 Triumph T120 Bonneville
Far North East Metro Denver Colorado
Please Log in or Create an account to join the conversation.
- SWest
- Offline
- Sustaining Member
- 10 22 2014
- Posts: 22972
- Thank you received: 2749
Steve
Please Log in or Create an account to join the conversation.
- KZB2 650
- Topic Author
- Offline
- User
- Posts: 1475
- Thank you received: 265
I will admit the marrage worked out and still is but it put a damper on my toys...... stuck with dirt bikes till the winter of 80 when I gave up on getting the cash for a new liter bike and bought the slightly used 650 ..... had it ever since and really can't complain about how things worked out. Didn't really learn much about Denco till much later when I saw the Bonneville bike article (mid 90s?) ...... thinking things would have been much different if I would have .... was more of a big RC/ Vance and Hines, APE and Yosh fan back then.
1978 KZ650 b-2
700cc Wiseco kit 10 to 1.
1980 KZ750 cam, ape springs, stock clutch/ Barnett springs.
Vance and Hines Header w/ comp baffle and Ape pods, Dyna S and green coils, copper wires.
29MM smooth bores W/ 17.5 pilots, 0-6s and 117.5 main
16/42 gearing X ring chain and alum rear JT sprocket.
Please Log in or Create an account to join the conversation.
- pete greek1
- Offline
- User
- Posts: 1510
- Thank you received: 185
& I, like almost all of my friends , took of the stock pipes & got a header on there, they all had Kerkers, V/H, RC, Yosh etc. I got me a Bassani which I loved, & had it on the bike until 2010 when the chrome started to peel off on the bottom & started to get rust pinholes, I sold it to a member here & he had the holes repaired & had it ceramic coated, I should've done that , SMH,
Bruce, do you have a pic. of the Denco on your bike
Pete
1980 LTD 1000..,1976 LTD 900, have the 1000&900 now. the rest are previous= 1978 KZ 650 B.., 1980 Yamaha XT 500..,1978 Yamaha DT 400.., 1977 Yamaha yz 80..,Honda trail ct 70.., Honda QA 50...5-1/2 hp brigs & straton CAT chopper mini bike...3-1/2 hp mini bike (WHEN GAS WAS ABOUT 45 CENTS A GALLON)!!!!
Please Log in or Create an account to join the conversation.
- zukdave
- Offline
- User
- Posts: 1685
- Thank you received: 229
1980 KZ650 F1
ZX750A1 motor.
Wiseco 810cc kit.
Zukiworks racing ported head.
VM 29 smooth bore's.
Dyna 2000 Ign. w/Dyna mini coil's
APE cylinder stud's and nut's.
APE valve spring's.
APE Track King clutch.
V/H KZ1000 sidewinder.
3.5x18 laced to a KZ1000 disk hub.
150/60/18 Shinko 006 Podium.
63" wheel base.
Please Log in or Create an account to join the conversation.
- BlackZ1R
- Offline
- User
- Kawasaki in my blood
- Posts: 702
- Thank you received: 47
What's your best # to date, Dave? What cc are you running now?zukdave wrote: I'm not far off their number's no bar, street tire and stock cams.
Kawasaki
Someone once told me to marry that motorcycle I was riding ......there's times I wish I hadda listened .
Please Log in or Create an account to join the conversation.
- zukdave
- Offline
- User
- Posts: 1685
- Thank you received: 229
Our track is 1/8th. mile so no 1/4 mile time's yet
but has gone 7.34@98.73 with a 1.61 60ft. 1/8th mile.
1980 KZ650 F1
ZX750A1 motor.
Wiseco 810cc kit.
Zukiworks racing ported head.
VM 29 smooth bore's.
Dyna 2000 Ign. w/Dyna mini coil's
APE cylinder stud's and nut's.
APE valve spring's.
APE Track King clutch.
V/H KZ1000 sidewinder.
3.5x18 laced to a KZ1000 disk hub.
150/60/18 Shinko 006 Podium.
63" wheel base.
