Changing tires
31 May 2024 20:36
Mounted new tires and tubes on the Z1 the other day. Turns out I haven't forgotten how to pinch a tube with the tire irons...
Scotty
1974 Z1A
1015
welded Z1 crank
Andrews 1X Cams
Delkevic 4 into 1
Superbike bars
530 conversion
Please Log in or Create an account to join the conversation.
- Wookie58
- Away
- Moderator
- Posts: 4422
- Thanks: 2581
Re: Changing tires
01 Jun 2024 00:32
1982 KZ1000 Ltd
www.kzrider.com/forum/11-projects/617631...-82-begins?start=192
kzrider.com/filebase-alias?view=download...d-fault-diagnosis&ca
www.kzrider.com/forum/11-projects/617631...-82-begins?start=192
kzrider.com/filebase-alias?view=download...d-fault-diagnosis&ca
The following user(s) said Thank You: sf4t7
Please Log in or Create an account to join the conversation.
- Warren3200gt
- Offline
- User
- Posts: 1516
- Thanks: 721
Re: Changing tires
01 Jun 2024 02:20 - 01 Jun 2024 02:21
Bike tyres can be tricky but the secret is to never let the tyre iron go further than 90deg to the rim. Use three irons, first one to hold the start seat then just go round with the other two leap fogging each other in no more than two inch bites remembering to ensure none of the three irons go no more than 90 deg.
The tube will only get nipped if the iron goes past 90 deg and springs flat against the tyre wall.
The tube will only get nipped if the iron goes past 90 deg and springs flat against the tyre wall.
Last edit: 01 Jun 2024 02:21 by Warren3200gt.
The following user(s) said Thank You: sf4t7
Please Log in or Create an account to join the conversation.
- DOHC
- Offline
- Sustaining Member
- Those Doe-Hawks really go!
- Posts: 1244
- Thanks: 556
Re: Changing tires
01 Jun 2024 06:46My first try at swapping a tire I pinched the tube, patched it, and pinched it again, and then went to the bike shop to get a new tube. As I'm walking out this old guy asked me if I wanted advice about installing the tube I was holding. I sure as heck did! He was standing by his late 60s BMW with over 250,000 miles on it, all ridden by him. He said he had gone all the way down to South America and back. I figured he was worth listening to.
He said the trick is to partially inflate the tube after you install it inside the tire, before you start going at it with the tire irons. Inflating it pushes the tube up into the tire carcass and doesn't leave any tube flaps down near the bead. It worked for me anyway.
'78 Z1-R in blue
, '78 Z1-R in black,
'78 Z1-R in pieces
My dad's '74 Z1
'00 ZRX1100
My dad's '74 Z1
'00 ZRX1100
The following user(s) said Thank You: slmjim+Z1BEBE, Nessism, sf4t7, SWest, Wookie58
Please Log in or Create an account to join the conversation.
- Nessism
- Away
- Sustaining Member
- Posts: 7526
- Thanks: 2883
Re: Changing tires
01 Jun 2024 07:20He said the trick is to partially inflate the tube after you install it inside the tire, before you start going at it with the tire irons. Inflating it pushes the tube up into the tire carcass and doesn't leave any tube flaps down near the bead. It worked for me anyway.
I concur with this advice. It helps greatly.
I'm a bicycle rider, and getting flats is part of the experience. I carry a tube with me at all times on the bike. Changed dozens of flats on the road. Some air in the tube makes a huge difference in avoiding pinching the tube while levering the sidewall in place.
Ed
Carb O-ring Kits : www.kzrider.com/forum/3-carburetor/61807...-o-ring-kits?start=0
www.kzrider.com/forum/faq-wiki/618026-new-owner-things-to-know
1981 KZ750E2
www.kzrider.com/forum/11-projects/604901...z750e-project-thread
Carb O-ring Kits : www.kzrider.com/forum/3-carburetor/61807...-o-ring-kits?start=0
www.kzrider.com/forum/faq-wiki/618026-new-owner-things-to-know
1981 KZ750E2
www.kzrider.com/forum/11-projects/604901...z750e-project-thread
The following user(s) said Thank You: sf4t7
Please Log in or Create an account to join the conversation.
- SWest
- Offline
- Sustaining Member
- 10 22 2014
- Posts: 23197
- Thanks: 2816
Re: Changing tires
01 Jun 2024 08:14
Been there done that. I always put a little air in the tube for that reason. The type of tire spoons makes the difference too. Changing to alloy rims changed everything. Not only is it damn near impossible to break the bead without nicking the tube doing it on the side of the road is out of the question. This time I'm going tubeless. I'll still carry my air pump I'll carry a plug kit. If I pick up a nail I'll stick a plug in it and ride on. Later I can put a patch or boot on the inside but I won't be STRANDED.
Steve
Steve
Z1b1000 1975 Z1b
kzrider.com/forum/11-projects/598262-kz-...-will-it-live#672882
kzrider.com/forum/2-engine/597654-poser?start=240#704229
kzrider.com/forum/11-projects/598262-kz-...-will-it-live#672882
kzrider.com/forum/2-engine/597654-poser?start=240#704229
Please Log in or Create an account to join the conversation.
- sf4t7
- Topic Author
- Offline
- Sustaining Member
- Posts: 630
- Thanks: 422
Re: Changing tires
01 Jun 2024 15:11
I usually do add a little air to the tube, lube the beads, and carefully lever it on. But... it was getting late, the front tire and tube went on easily, and we went past 90 degrees on the last couple tries. Should have known better... At least I also remember how to patch the tube.
