differences in models
- Kech65
- Topic Author
- Offline
- User
Less
More
06 May 2016 11:02 #724898
by Kech65
differences in models was created by Kech65
Hey Everyone!
I have a 1981 750 project
I'm working on and As i'm searching for parts i notice a lot of kz750 ltd and kz750b variations. I have a kz750h but what is the differences in the models?
I have a 1981 750 project
I'm working on and As i'm searching for parts i notice a lot of kz750 ltd and kz750b variations. I have a kz750h but what is the differences in the models?
Please Log in or Create an account to join the conversation.
- Nebr_Rex
- Offline
- User
Less
More
- Posts: 1887
- Thank you received: 295
06 May 2016 19:06 #724978
by Nebr_Rex
2002 ZRX1200R
81 GPz1100
79 KZ1000st daily ride
79 KZ1000mk2 prodject
78 KZ650sr
78 KZ650b
81 KZ750e
80 KZ750ltd
77 KZ400/440 cafe project
76 KZ400/440 Fuel Injected
www.dotheton.com/forum/index.php?topic=39120.0
.
Replied by Nebr_Rex on topic differences in models
KZ750h is the ltd. the b models are 2 cylinder twins.
2002 ZRX1200R
81 GPz1100
79 KZ1000st daily ride
79 KZ1000mk2 prodject
78 KZ650sr
78 KZ650b
81 KZ750e
80 KZ750ltd
77 KZ400/440 cafe project
76 KZ400/440 Fuel Injected
www.dotheton.com/forum/index.php?topic=39120.0
.
The following user(s) said Thank You: Kech65
Please Log in or Create an account to join the conversation.
- martin_csr
- Offline
- User
Less
More
- Posts: 8019
- Thank you received: 1645
07 May 2016 06:40 - 07 May 2016 07:30 #725034
by martin_csr
Replied by martin_csr on topic differences in models
Your bike is a 750-4 Ltd chain drive. closest match = 80-83 KZ750-H1/2/3/4. most stuff is the same.
The 81-83 650-csr shares a number of parts with the Ltd. same ign & charging sys. most chrome stuff.
next would be the 80-82 KZ750-E1/2/3, but the 750E is a standard model. some stuff will interchange, but it depends upon the part
The 81-83 650-csr shares a number of parts with the Ltd. same ign & charging sys. most chrome stuff.
next would be the 80-82 KZ750-E1/2/3, but the 750E is a standard model. some stuff will interchange, but it depends upon the part
Last edit: 07 May 2016 07:30 by martin_csr.
The following user(s) said Thank You: Kech65
Please Log in or Create an account to join the conversation.
- GPzMOD750
- Offline
- User
Less
More
- Posts: 1365
- Thank you received: 148
07 May 2016 14:43 - 07 May 2016 19:29 #725076
by GPzMOD750
Replied by GPzMOD750 on topic differences in models
The "model" numbers can be confusing. When you are looking for Kwaker parts you will run into 2 categories of model numbers, the production model or the one listed on the frame label and the marketing model the one on the side cover they usually don't match at all. These get confused all the time what makes it worse is those that aren't familiar with the 2 separate systems will mix up the 2 designations.
For example my bike is a GPz750, Since it's a 1982 the production model is KZ750R1. I have to look for parts in many combinations using those 2 model designations AND the model year especially since it's a one off model. Many times I will find parts listed as fitting GPz750R(1) which isn't correct at all but helps distinguish it from later GPz750 models which were ZX750 production models. Another issue is that in European market the "K" was dropped from the model designations so over there my bike's production model is the Z750R1.
It's taken a little while but I have figured out most of the combinations of model designations i need to use to find parts for my bike. I've also figured out what models have some identical and/or interchangeable parts.
One thing that is good to know is that the ZR7 (production model ZR750) That was built from about 99-05 has used a slightly updated KZ750 engine and many parts will bolt onto the KZ650s and KZ750s with no or minor mods.
Good luck and we look forward to seeing your project thread and the biggest rule around here is you must take and post many, many pics.
For example my bike is a GPz750, Since it's a 1982 the production model is KZ750R1. I have to look for parts in many combinations using those 2 model designations AND the model year especially since it's a one off model. Many times I will find parts listed as fitting GPz750R(1) which isn't correct at all but helps distinguish it from later GPz750 models which were ZX750 production models. Another issue is that in European market the "K" was dropped from the model designations so over there my bike's production model is the Z750R1.
It's taken a little while but I have figured out most of the combinations of model designations i need to use to find parts for my bike. I've also figured out what models have some identical and/or interchangeable parts.
One thing that is good to know is that the ZR7 (production model ZR750) That was built from about 99-05 has used a slightly updated KZ750 engine and many parts will bolt onto the KZ650s and KZ750s with no or minor mods.
Good luck and we look forward to seeing your project thread and the biggest rule around here is you must take and post many, many pics.
Last edit: 07 May 2016 19:29 by GPzMOD750.
Please Log in or Create an account to join the conversation.
- Kech65
- Topic Author
- Offline
- User
Less
More
- Posts: 13
- Thank you received: 0
09 May 2016 11:49 #725363
by Kech65
Replied by Kech65 on topic differences in models
Thanks Man! You guys are great help!
Please Log in or Create an account to join the conversation.
- Patton
- Offline
- KZr Legend
Less
More
- Posts: 18640
- Thank you received: 2098
09 May 2016 20:07 - 09 May 2016 20:23 #725447
by Patton
1973 Z1
KZ900 LTD
Replied by Patton on topic differences in models
KZ750 twin models can be identified with the acrostic phrase: My Kawasaki By God.
My Kawasaki By God.
4 words = 4 B models and 4 non-B models
Yes, I know. :lol:
Kawasaki KZ750 750cc 4-cycle twin
1976 Kawasaki KZ750-B1
1977 Kawasaki KZ750-B2
1978 Kawasaki KZ750-B3
1979 Kawasaki KZ750-B4
1980 Kawasaki KZ750-G1
1982 Kawasaki KZ750-M1
1983 Kawasaki KZ750-K1
1984 Kawasaki KZ750-K2
Per KZXr member, steell:
76-79 KZ750 were the "B" model, single disc front and rear with wire spoke wheels.
1980 KZ750G, pretty much the same as the "B", but with rear drum brake and mag wheels.
1981 model 750 twin doesn't exist.
1982 KZ750M1 CSR, same motor as the "B" and "G", with air injection into the exhaust, with wire wheels and rear drum brake.
1983 KZ750K1, same as M1 except for belt drive.
1984 KZ750K2, Canada only, same as K1.
Good Fortune!
My Kawasaki By God.
4 words = 4 B models and 4 non-B models
Yes, I know. :lol:
Kawasaki KZ750 750cc 4-cycle twin
1976 Kawasaki KZ750-B1
1977 Kawasaki KZ750-B2
1978 Kawasaki KZ750-B3
1979 Kawasaki KZ750-B4
1980 Kawasaki KZ750-G1
1982 Kawasaki KZ750-M1
1983 Kawasaki KZ750-K1
1984 Kawasaki KZ750-K2
Per KZXr member, steell:
76-79 KZ750 were the "B" model, single disc front and rear with wire spoke wheels.
1980 KZ750G, pretty much the same as the "B", but with rear drum brake and mag wheels.
1981 model 750 twin doesn't exist.
1982 KZ750M1 CSR, same motor as the "B" and "G", with air injection into the exhaust, with wire wheels and rear drum brake.
1983 KZ750K1, same as M1 except for belt drive.
1984 KZ750K2, Canada only, same as K1.
Good Fortune!
1973 Z1
KZ900 LTD
Last edit: 09 May 2016 20:23 by Patton.
Please Log in or Create an account to join the conversation.
- Kech65
- Topic Author
- Offline
- User
Less
More
- Posts: 13
- Thank you received: 0
11 May 2016 07:47 #725707
by Kech65
Replied by Kech65 on topic differences in models
I'm thinking about buying a tank from a 81 spectre 1100. It looks like it'll fit fine with some minor adjustments but I dont want to drop over 100 dollars if its not going to sit right. Have you had any luck with Specture parts? should it work on my kz750?
