- Posts: 822
- Thank you received: 52
Any tips on using the 2K Spray Max?
- kzz1king
- Topic Author
- Offline
- User
Wayne
74 Z1 1075, 29 smoothbores, owned and ridden since 1976
Home built KZ1000 turbo setup
www.kzrider.com/forum/11-projects/532476...s-budget-turbo-build
www.kzrider.com/forum/11-projects/532489-74-z-makeover
Please Log in or Create an account to join the conversation.
- z1kzonly
- Offline
- User
- Sustaining Member
- Posts: 2817
- Thank you received: 524
I assume the clear coat. No thin coats! Wet, medium cover. Shiney lookin at you. Overlap wet coats.
You only need 3 coats at most of clear. Adjust your gun to shot a like "Eyeball" pattern.
No dry coats! Slow even pattern 5-10 minutes between coats. Depending on temp. and the activator, slow, med, high temp range. More confused now?? Ha Ha. Pratice on a piece of anything, Small part or piece of sheet metal. Go with the fastest dry tme stuff. Low temp. Your spray gun will have 2 adjustments fluid and air. Search Youtube, probally a million paint tutorials.
I always shot at the door to fine tune my spray pattern, mostly primer and color.
Good luck, watch some of the car retoration shows. That helps too.
Livin in "CheektaVegas, NY
Went thru 25 of these in 40 yrs.
I SOLD OUT! THE KAW BARN IS EMPTY.
More room for The Old Girl, Harley 75 FLH Electra Glide,
Old faithful! Points ign. Bendix Orig. carb.
Starts everytime!
Please Log in or Create an account to join the conversation.
- kzz1king
- Topic Author
- Offline
- User
- Posts: 822
- Thank you received: 52
Wayne
74 Z1 1075, 29 smoothbores, owned and ridden since 1976
Home built KZ1000 turbo setup
www.kzrider.com/forum/11-projects/532476...s-budget-turbo-build
www.kzrider.com/forum/11-projects/532489-74-z-makeover
Please Log in or Create an account to join the conversation.
- kaw-a-holic
- Offline
- User
- Posts: 1808
- Thank you received: 249
" APPLICATION INSTRUCTIONS
Ceramic Chassis Black may be applied using an HVLP gun with a 1.3 mm—1.7 mm fluid tip. Apply in two medium wet coats, allowing 15-20 minutes flash between coats. A dry film thickness of 2 mils is recommended. If required for improved flow and leveling, Ceramic Chassis Black may be reduced by up to 10% with a high-quality Urethane-Grade Reducer such as Eastwood’s Zero VOC Reducer (50104ZP)."
Not sure if this helps. There videos on YouTube did not give dry/tack times either.
Jon
1977 KZ1000a1
Mesa, AZ
Phoenix Fighter Project
Please Log in or Create an account to join the conversation.
- Kawboy74
- Offline
- User
- Posts: 319
- Thank you received: 52
Good luck.
David
1974 Z1A As original as I could get it
'88 ZX750R braided lines, mostly original
KZ1000 project on the bench
Burlington,Ontario,Canada
Please Log in or Create an account to join the conversation.
- kzz1king
- Topic Author
- Offline
- User
- Posts: 822
- Thank you received: 52
Wayne
Kawboy74 wrote: Make sure you have the correct temperature in the area where you are going to apply it, and for a decent amount of time after. Have all your parts lined up and ready as you only have about 24 - 36 hours to use up the can once mixed together, and that is keeping it somewhat cool. Get any buffing or wet-sanding done as soon as it dries so that you can re-coat soon if necessary. I am waiting for good temperatures to do the same but at $33.00 a can I am not going to waste it.
Good luck.
David
74 Z1 1075, 29 smoothbores, owned and ridden since 1976
Home built KZ1000 turbo setup
www.kzrider.com/forum/11-projects/532476...s-budget-turbo-build
www.kzrider.com/forum/11-projects/532489-74-z-makeover
Please Log in or Create an account to join the conversation.
- ramtough_63
- Offline
- User
medium wet coats few minutes flash time make sure you take your time and overlap you will see it burn in as you go
couple of coats should do it if your not covering artwork or striping
1978 KZ1000 A2
Thrown Together To Ride Til Winter
Facebook Page
Free Range Custom Art
1982/83 750R/GPZ
1984 Goldwing 1200 Interstate
1982 Yamahopper QT50
Previous
2 79 HD sporty XLH
02 HD FLSTS Heritage
60's HD Hummer
70's Honda 550 Four
70 Yamaha 100
and various enduros dirtbikes minibikes...
Please Log in or Create an account to join the conversation.
- DesertKZ
- Offline
- User
- Posts: 227
- Thank you received: 20
1979 KZ1000 Shaft
1979 CX500C
1975 GT750 Smoker
Please Log in or Create an account to join the conversation.
- richard_oxon
- Offline
- User
- Posts: 37
- Thank you received: 4
Attachment myz1000paintjob.jpg not found
i used the same spraymax in a can. you need to use it all with in a day or two ,light coat first then keep building it up . a few mins between coats took a while to dry maybe 18 hours or so . i did mine out side on a nice warm day . works nice and gas dosent hurt it at all .
** KZ1000 B3 1979 ** 1015cc wiseco pistons 33 smoothbores ported head 410 cams
** KZ1000 A1 1977** 1075 wiseco pistons 438 megacycle cams ported head rs34 flat slides
Please Log in or Create an account to join the conversation.
- Kidkawie
- Offline
- User
- I bleed premix
- Posts: 1913
- Thank you received: 243
You'll probably get some orange peel so wet sand it out with 1500 then 2000, then buff with polish and wax.
1975 Z1 900
1994 KX250 Supermoto
2004 KX125
Please Log in or Create an account to join the conversation.
