Plating at home 06 Jan 2021 18:32 #841255

  • katit
  • katit's Avatar
  • Offline
  • User
  • Posts: 257
  • Thank you received: 14
You answered my next questions:)

PS I got is more expensive one, 10amps but I paid $50 in 2019

On prep: what do you think about blasting parts? Or it’s not practical for small bolts? Or it will leave too coarse surface?

If I am going to use acid for old plating removal, where is wire wheel coming to play?

I was thinking something simple like
Clean/degrease to get crud and oils off - simple green
Then maybe soda blast to get any remnants off and keep metal
Bath in acid to slightly etch and get through old plating

Then rinse and plate

No?

Another question what do you use for heaters? Degreaser need to be 200f and plating at 100F

Watced some videos the suggested fish tank heater but those go up to 90f only

Please Log in or Create an account to join the conversation.

Last edit: by katit.

Plating at home 06 Jan 2021 19:19 #841257

  • Nessism
  • Nessism's Avatar
  • Offline
  • Sustaining Member
  • Posts: 5649
  • Thank you received: 1670
That process sounds reasonable. I think the kit comes with some caustic solution to degrease so if that's the case, I'd use that instead of the simple green...or save that as your last step before plating.

The wire wheel is good to polish the metal. The brighter the metal finish the brighter the platting finish.
The following user(s) said Thank You: katit

Please Log in or Create an account to join the conversation.

Plating at home 06 Jan 2021 19:23 #841258

  • katit
  • katit's Avatar
  • Offline
  • User
  • Posts: 257
  • Thank you received: 14
Btw, this is video I refer to. Temperature seems to be important

Please Log in or Create an account to join the conversation.

Plating at home 06 Jan 2021 19:55 #841260

  • hardrockminer
  • hardrockminer's Avatar
  • Offline
  • Sustaining Member
  • Posts: 1711
  • Thank you received: 514
I was going to post a couple of pages from my Caswell manual but it's copyrighted material so I can't do it. But I would highly recommend purchasing the manual. It contains a lot of good advice on how to properly plate. There are a lot of variables, and controlling them is key to good results.

One point they make in the manual is that bead blasting is the best way to clean surfaces and get a good result.
I have a couple of Z1B's restored, an '80 KZ1000LTD restored, a 1981 KZ550 restored and a 2008 KLR 650 for off road fun. My wife has a 2019 Suzuki DR 650 for on and off road.

Please Log in or Create an account to join the conversation.

Plating at home 07 Jan 2021 07:10 #841267

  • scubaanders
  • scubaanders's Avatar
  • Offline
  • Sustaining Member
  • Posts: 422
  • Thank you received: 135
After brushing of my fingertips with the steel brush trying to clean m6 bolts I started vapour blasting them. But you can not dry blast them, it takes of to much material and you will damage the treads.
Except for that I really enjoy having my kit and being able to add that extra bling.
The brightener by the way is glucose.
But if you turn up the current to high after adding the brightener it will turn in too sot.


/A

Please Log in or Create an account to join the conversation.

Last edit: by scubaanders.

Plating at home 07 Jan 2021 07:47 #841268

  • katit
  • katit's Avatar
  • Offline
  • User
  • Posts: 257
  • Thank you received: 14

After brushing of my fingertips with the steel brush trying to clean m6 bolts I started vapour blasting them. But you can not dry blast them, it takes of to much material.

/A


Maybe soda blast? Takes little or none.

As hardrockminer mentioned - bead blasting might be correct way, but again, maybe on flat brackets, etc. Not bolts..

Watched couple videos yesterday on different things people do. Some people after degreasing just dip hardware in acid for 10 minutes to take old coating and any rust off. And THEN, wire wheel them to make them shiny again.

Please Log in or Create an account to join the conversation.

Plating at home 07 Jan 2021 09:41 #841276

  • Kaylinator
  • Kaylinator's Avatar Topic Author
  • Offline
  • Sustaining Member
  • Posts: 294
  • Thank you received: 68
Supposedly, if you reverse the positive and negative clips in the plate tank, it will reverse the process and remove old plating from bolts...

Please Log in or Create an account to join the conversation.

Plating at home 07 Jan 2021 09:46 #841278

  • katit
  • katit's Avatar
  • Offline
  • User
  • Posts: 257
  • Thank you received: 14

Supposedly, if you reverse the positive and negative clips in the plate tank, it will reverse the process and remove old plating from bolts...


Absolutely. And, in turn it will deposit whatever coating you have on old parts on your anodes.
This might be practical (in my mind) only if you deal with same type of hardware and have separate tank for de-plating.

Please Log in or Create an account to join the conversation.

Plating at home 07 Jan 2021 10:29 #841280

  • davido
  • davido's Avatar
  • Offline
  • User
  • Posts: 1533
  • Thank you received: 253

Supposedly, if you reverse the positive and negative clips in the plate tank, it will reverse the process and remove old plating from bolts...


Absolutely. And, in turn it will deposit whatever coating you have on old parts on your anodes.
This might be practical (in my mind) only if you deal with same type of hardware and have separate tank for de-plating.


Rust also.
www.kzrider.com/forum/11-projects/594313-csr1000-project-build
CB550
(CB500/4)
(CBX750)
GSF600
KZ1000CSR
XT 600e

Please Log in or Create an account to join the conversation.

Plating at home 07 Jan 2021 11:17 #841283

  • Nessism
  • Nessism's Avatar
  • Offline
  • Sustaining Member
  • Posts: 5649
  • Thank you received: 1670
I glass bead blast nuts and bolts all the time and no material is removed, other than a little of the old plating.

If you dunk a zinc plated part in diluted HCl it will fizz until all the zinc is gone. That's when you take it out and rinse.

Please Log in or Create an account to join the conversation.

Plating at home 07 Jan 2021 13:11 #841291

  • Mikaw
  • Mikaw's Avatar
  • Offline
  • Sustaining Member
  • Posts: 2629
  • Thank you received: 648
I dont do any home plating but i can tell you the guy that does my re-plate loves the way I send him my hardware. I degrease as best as I can here at home, chase the threads and try to gently remove burs and wrench boogers. Then they go to Vapor Blasting shop where he uses an aircraft strength degreaser, then V-Blasts the hardware. He will put all the nuts and washers on mechanics wire so they dont get blasted around the cabinet. They get dried to prevent a flash rust and he places a WD40 soaked blue shop towel into the zip lock with the hardware. I like the finish and the quality of the re-plating I get using this method.

If anyone is looking for quality Vapor Hone Shop here is his contact.

1976 KZ 900 A4 kzrider.com/forum/11-projects/613548-1976-kz-900-a4
1976 KZ 900 B1 LTD
1978 KZ 1000 B2 LTD
Kowledge Speaks, But Wisdom Listens.
Jimi Hendrix.
Attachments:

Please Log in or Create an account to join the conversation.

Last edit: by Mikaw.

Plating at home 07 Jan 2021 23:21 #841319

  • scubaanders
  • scubaanders's Avatar
  • Offline
  • Sustaining Member
  • Posts: 422
  • Thank you received: 135
Ok so let’s look at it from a scientific perspective.

Zink plating is a rust inhibiter technic, zinc is more reactive than steel and will act like a sacrificial metal and will corrode before the steel does so. In order to inhibit the zinc to corrode to quickly the zinc can be passivated with a passivate like a chromate that bounds the outer electron layer on the zinc, thereby making the zinc less reactive and less prone to corrosion.

Therefor we zinc plate fasteners usually with a coating of zinc 5-25 microns thick and then dip it in a passivate that will end up less than 1 micron thick.
I order to get the zinc to stick to the metal the metal needs to be clean, free from rust och grease.
In most of the cases our fasteners are both greasy and rusty and we need to get them spanking clean before we plate them.

1. If greasy.
Soak in diesel for a day and shake the container from time to time, resorting to equal solves equal and thereby getting the diesel to dissolve grease. Then soak in a petrochemical degreaser for a while, rinse in scalding hot water. Then soak in a alkaline degreaser for a while, rinse in scalding hot water again.
Now your fasteners should be free of grease. They might still be rusty though.

2. If rusty.
Rust can be removed in many different ways,
• mechanically with a steel brush
• by blasting, wet or dry, with less ore more aggressive blasting media. Just make sure your method doesn’t remove too much goods from your fasteners as they will go out of dimension. Dry sand is very aggressive, plastic beds, walnut shells, Vapor blasting, soda and dry ice the least aggressive.
• reverse electrolysis is also a method, but it’s quite cumbersome hanging bolts and nuts in the bath and you will need to remove the black ferrite that will form on the fasteners from the reversed rust.
• Chemically with acid, my favorite method. The more aggressive acid the faster it will dissolve the rust, but be careful because an aggressive acid like HCL will also dissolve the iron in your fasteners if you leave it in for to long.

So now that your fasteners are clean and free of rust its time to set up your plating set.

I set up 7 different plastic tubs and always go through the complete cycle even if my fasteners has just been cleaned with any of the methods described above.
I hang my fasteners in copper wire and start dipping

1. Alkaline degreaser
Just to make sure that there is no grease, remember fingers might be fatty, dip in the degreaser and leave for a couple of minutes.

2. Distilled water
Then a dip in distilled water to get rid of the degreaser.

3. Acid
I use 30% HCL which is pretty aggressive, I looks at the fizzing and when the fasters look clean and the fizzing slows down its done. No need to remove all the zinc but you need a spakning clean surface to get the zinc to plate to.
You can use a less aggressive acid, it might just take a little bit longer.
White vinegar (acetic acid), Tile cleaner (phosphoric acid) at ca 30% can be good alternatives to HCL (hydrochloric acid).

4. Distilled water
Then a dip in water to get rid of the acid.

5. Plating solution
I preheat my plating solution by placing the plastic can where I store the solution in a bucket with scalding hot water in before filling up my plating tub.
The tub is also equipped with an aquarium heater set at 25⁰ C and an aquarium air pump that makes sure the solution is circulated.
Before dropping my zinc anodes into the bath I give the a good brush of and make sure the copper wires has a good connection.
Makes sure I connect the polarity right and then hang my fasteners for plating.
If the fasteners come out dull I rise the current a bit and try again and might add brightener.

As Nessism wrote, let the solution sit for a while every now and then and siphon of the plating solution in order to get rid of the muck that will fall to the bottom of the can when stored.

Some items are a bitch to plate, like inside insex sockets, inside swingarm pivot tubes and might require some moving around and makings sure the solution are able to flow through while plating. If consider that the zinc atoms shall leave the anodes and travel to your fastener through the solution, the atoms will need a clear line of travel in order to attach to the right spot on your goods.

Power source, a bike battery can be used as a power source with some kind of rheostat like a wolfram coil, but a good power supply with a amp meter is the best.

6. Distilled water
Now a last dip in water

7. Passivate
Dip and leave in the passivate for 3-4 minutes

8. Hang to dry

Do I need to say that even though the stuff used to day is not highly toxically, its not meant for human consumption, its pretty nasty stuff and shall be handled and stored accordingly. Passivate used to contain hexavalent chromium that is seriously bad for you, nowadays not so much, they have come up with new solutions but it should still be handled with outmost respect and 30% HCL will hurt you.

Like Nessism I restore carburetors and a lot of the parts on eighties jap bike carburetors are made of unobtanium, therefor are no longer available on the open market and replating is the only option.

Happy dipping!

/Anders
