need pictures of braced drum brake swingarms

  • trianglelaguna
  • trianglelaguna's Avatar Topic Author
  • Offline
  • User
  • User
    Registered
  • New and improved - extra strength
  • Posts: 8030
  • Thanks: 235

need pictures of braced drum brake swingarms

05 Jun 2013 19:10 - 05 Jun 2013 21:16
#590974
Getting ready to have a member make bracing on my stock kz900drum brake swingarm ....was wondering if anyone has pictures of kz's -Z's with drum arms that have been webbing/ braced?
Thanks
Craig
1976 KZ900
2003 ZX12R
2007 FZ1000
2004 ninja 250R for wife
Last edit: 05 Jun 2013 21:16 by trianglelaguna.

Please Log in or Create an account to join the conversation.

  • kzz1king
  • kzz1king's Avatar
  • Offline
  • User
  • User
    Registered
  • Posts: 822
  • Thanks: 52

Re: need pictures of braced drum brake swingarms

05 Jun 2013 20:13
#590979
You got me curious about this now. Watching.
Wayne
74 Z1 1075, 29 smoothbores, owned and ridden since 1976
Home built KZ1000 turbo setup

www.kzrider.com/forum/11-projects/532476...s-budget-turbo-build

www.kzrider.com/forum/11-projects/532489-74-z-makeover

Please Log in or Create an account to join the conversation.

  • trianglelaguna
  • trianglelaguna's Avatar Topic Author
  • Offline
  • User
  • User
    Registered
  • New and improved - extra strength
  • Posts: 8030
  • Thanks: 235

Re: need pictures of braced drum brake swingarms

05 Jun 2013 21:15
#590987
this is a disc brake...but i like the lay out of the bracing a lot...would need to go topside...i guess the brake arm could be mounted to the brace if it was underside....but i think the stay arm and drum would be better left in the position it is now
