Spark, fuel and compression but won't start
27 Feb 2017 14:49
Hi guys I have a 1980 kz440 it has good compression gets fuel and spark but it still won't start, does anyone have any idea what it could be? Thanks for the help
Please Log in or Create an account to join the conversation.
- Nessism
-
- Offline
- Sustaining Member
-

Registered
- Posts: 8205
- Thanks: 3577
Re: Spark, fuel and compression but won't start
27 Feb 2017 15:24
Have you gone through the carbs completely and clean all the passages and jets?
Is the bike stock? Reason for mentioning is because if for some reason you are trying to start the bike without the airbox or with pods you may struggle because the mixture will be all wrong.
Is the bike stock? Reason for mentioning is because if for some reason you are trying to start the bike without the airbox or with pods you may struggle because the mixture will be all wrong.
Ed
Carb O-ring Kits : www.kzrider.com/forum/14-vendor-forum/62...rburetor-o-ring-kits
www.kzrider.com/forum/faq-wiki/618026-new-owner-things-to-know
1981 KZ750E2
www.kzrider.com/forum/11-projects/604901...z750e-project-thread
Carb O-ring Kits : www.kzrider.com/forum/14-vendor-forum/62...rburetor-o-ring-kits
www.kzrider.com/forum/faq-wiki/618026-new-owner-things-to-know
1981 KZ750E2
www.kzrider.com/forum/11-projects/604901...z750e-project-thread
The following user(s) said Thank You: travism
Please Log in or Create an account to join the conversation.
- travism
-
Topic Author
- Offline
- User
-

Registered
- Posts: 5
- Thanks: 0
Re: Spark, fuel and compression but won't start
27 Feb 2017 16:25
I swapped the original carbs with vm30s with pod filters, the fuel is coming out of the carbs but it doesn't seem like it's getting sucked into the engine
Please Log in or Create an account to join the conversation.
- TexasKZ
-
- Offline
- Platinum Member
-

Registered
- Posts: 8405
- Thanks: 2789
Re: Spark, fuel and compression but won't start
27 Feb 2017 16:43
If fuel is running out of the carbs, either the fuel level is too high, or the float valves are not sealing due to dirt, corrosion or a mechanical blockage. This needs to be addressed before trying to start it again. Also, if this model has a vacuum operated petcock (fuel valve) it has likely failed as well. It will need a careful cleaning and its rubber parts will need to be replaced. If you know of somebody who has successfully made this carb swap on a 440, you may be able to use their jetting as a place to start.
Are the carb holders in really good shape? ie, pliable and without surface cracks? Do the new carbs fit snugly in them? If not, they will need to be replaced.
As already mentioned, the carbs need to be spotless inside, and every one of those tiny passageways need to be perfectly clear. A can of aerosol cab cleaner, some really small wire and compressed air will often do the job. If they are really cruddy, an ultrasonic cleaning may be the only solution.
Are the carb holders in really good shape? ie, pliable and without surface cracks? Do the new carbs fit snugly in them? If not, they will need to be replaced.
As already mentioned, the carbs need to be spotless inside, and every one of those tiny passageways need to be perfectly clear. A can of aerosol cab cleaner, some really small wire and compressed air will often do the job. If they are really cruddy, an ultrasonic cleaning may be the only solution.
1982 KZ1000 LTD parts donor
1981 KZ1000 LTD slowly moving toward resurrection
2000 ZRX1100 not ridden enough
www.kzrider.com/forum/11-projects/620336...amateur-build-thread
1981 KZ1000 LTD slowly moving toward resurrection
2000 ZRX1100 not ridden enough
www.kzrider.com/forum/11-projects/620336...amateur-build-thread
The following user(s) said Thank You: GPz550D1
Please Log in or Create an account to join the conversation.
- travism
-
Topic Author
- Offline
- User
-

Registered
- Posts: 5
- Thanks: 0
Re: Spark, fuel and compression but won't start
27 Feb 2017 17:05
Thanks! Im about to order new rubber boots and I didn't even think about adjusting the fuel level on the carbs (I'm new to fixing bikes) and I'm going to look into new jets for it
Please Log in or Create an account to join the conversation.
- Barry2
-
- Offline
- User
-

Registered
- Posts: 126
- Thanks: 23
Re: Spark, fuel and compression but won't start
27 Feb 2017 22:53
Getting spark at the right time?
1976 KZ900
Please Log in or Create an account to join the conversation.
- Scirocco
-
- Offline
- Premium Member
-

Registered
- Never change a running system
- Posts: 4397
- Thanks: 2262
Re: Spark, fuel and compression but won't start
28 Feb 2017 00:42
My 1975 Z 1 B 900 Project
www.kzrider.com/forum/11-projects/605133...ears-deep-sleep-mode
www.kzrider.com/forum/11-projects/605133...ears-deep-sleep-mode
The following user(s) said Thank You: GPz550D1, Nessism
Please Log in or Create an account to join the conversation.
- travism
-
Topic Author
- Offline
- User
-

Registered
- Posts: 5
- Thanks: 0
Re: Spark, fuel and compression but won't start
01 Mar 2017 22:21
i should be, i did the ignition timing
Please Log in or Create an account to join the conversation.
- travism
-
Topic Author
- Offline
- User
-

Registered
- Posts: 5
- Thanks: 0
Re: Spark, fuel and compression but won't start
01 Mar 2017 22:24
i bought one online acouple days ago and it just came in
Please Log in or Create an account to join the conversation.
- Tyrell Corp
-
- Offline
- User
-

Registered
- "You were made as well as we could make you"
- Posts: 1647
- Thanks: 262
Re: Spark, fuel and compression but won't start
02 Mar 2017 00:55
Uk Haynes are pretty good too, with workarounds if you don't have all the factory tools.
1980 Gpz550 D1, 1981 GPz550 D1. 1982 GPz750R1. 1983 z1000R R2. all four aces
