Re: H4 conversion ?
17 Jan 2017 23:12 - 17 Jan 2017 23:15
Nerdy, That lens is only 6 1/4" in diameter. And Nic, already have all the stock mounting hardware as my KZ headlight is complete and working. Just trying to switch from sealed beam unit to H4.
And Swest, I'm assuming just purchase the Emgo H4 lens from your Link and it will bolt right into my stock headlight hardware ?
And Swest, I'm assuming just purchase the Emgo H4 lens from your Link and it will bolt right into my stock headlight hardware ?
77' KZ1000A
Last edit: 17 Jan 2017 23:15 by kzdcw.
Please Log in or Create an account to join the conversation.
- Nessism
-
- Away
- Sustaining Member
-
Registered
- Posts: 7717
- Thanks: 3097
Re: H4 conversion ?
18 Jan 2017 05:32 - 18 Jan 2017 05:38
No eBay APP ID and/or Cert ID defined in Kunena configurationI converted a GS550 from sealed beam to H4 by simply purchasing an H4 lamp assembly in the same size and screwing it into the stock bucket. Couldn't be simpler. Many motorcycles use common 7" headlamps so that makes it easy. I bought mine off JC Whitney but it seems they don't sell them any longer. I'm sure there are other sources though...
Lots of options on ebay. This is just one.
Lots of options on ebay. This is just one.
Ed
Carb O-ring Kits : www.kzrider.com/forum/3-carburetor/61807...-o-ring-kits?start=0
www.kzrider.com/forum/faq-wiki/618026-new-owner-things-to-know
1981 KZ750E2
www.kzrider.com/forum/11-projects/604901...z750e-project-thread
Carb O-ring Kits : www.kzrider.com/forum/3-carburetor/61807...-o-ring-kits?start=0
www.kzrider.com/forum/faq-wiki/618026-new-owner-things-to-know
1981 KZ750E2
www.kzrider.com/forum/11-projects/604901...z750e-project-thread
Last edit: 18 Jan 2017 05:38 by Nessism.
Please Log in or Create an account to join the conversation.
- 78z1Joe
-
- Offline
- User
-
Registered
- My man cave is my garage....
- Posts: 85
- Thanks: 21
Re: H4 conversion ?
18 Jan 2017 06:51
Wow I'm looking at doing the same. I found a candlepower 7" H-4 replacement at Dennis Kirk. It's a quartz round lamp that should fit. Need to do some more research but claims to fit $38.00 with 60/55 watt bulb.
Let me know what you think.
Let me know what you think.
1978 KZ 1000
1982 GS 300 training bike
Previous Rides...
75 RD 350
72 CB 500 Four
72 SL 125
71 CT 70
69 3 1/2 HP mini bike
1982 GS 300 training bike
Previous Rides...
75 RD 350
72 CB 500 Four
72 SL 125
71 CT 70
69 3 1/2 HP mini bike
The following user(s) said Thank You: GPz550D1
Please Log in or Create an account to join the conversation.
- martin_csr
-
- Offline
- User
-
Registered
- Posts: 8018
- Thanks: 1645
Re: H4 conversion ?
18 Jan 2017 08:02 - 18 Jan 2017 08:40
nevermind. didn't see the one Nessism linked.
Last edit: 18 Jan 2017 08:40 by martin_csr.
Please Log in or Create an account to join the conversation.
- kzdcw
-
Topic Author
- Offline
- User
-
Registered
- 77' KZ1000A
- Posts: 857
- Thanks: 13
Re: H4 conversion ?
18 Jan 2017 08:03
Nessism, I pulled the headlight assembly apart and looked at the back side of my sealed beam lamp. Has 3 locating tabs for the mounting ring. Compared my lamp with others on eBay i.e.. Emgo # 66-75806 Looks the same as my stock lamp. So should be a go.
Even though tis H4 lamp comes with a 60/55W bulb what Wattage bulb should I use or would this one be alright ?
Even though tis H4 lamp comes with a 60/55W bulb what Wattage bulb should I use or would this one be alright ?
77' KZ1000A
Please Log in or Create an account to join the conversation.
- kzdcw
-
Topic Author
- Offline
- User
-
Registered
- 77' KZ1000A
- Posts: 857
- Thanks: 13
Re: H4 conversion ?
18 Jan 2017 08:23 - 18 Jan 2017 08:24
Found the Wattage rating of the stock Stanley 001-1014 lamp 50/35 Watts.
So I'm wondering if this Emgo lamp ( 60/55W ) will be alright ?
So I'm wondering if this Emgo lamp ( 60/55W ) will be alright ?
77' KZ1000A
Last edit: 18 Jan 2017 08:24 by kzdcw.
Please Log in or Create an account to join the conversation.
- Nessism
-
- Away
- Sustaining Member
-
Registered
- Posts: 7717
- Thanks: 3097
Re: H4 conversion ?
18 Jan 2017 10:49
You will be fine with that 60/55W bulb.
Ed
Carb O-ring Kits : www.kzrider.com/forum/3-carburetor/61807...-o-ring-kits?start=0
www.kzrider.com/forum/faq-wiki/618026-new-owner-things-to-know
1981 KZ750E2
www.kzrider.com/forum/11-projects/604901...z750e-project-thread
Carb O-ring Kits : www.kzrider.com/forum/3-carburetor/61807...-o-ring-kits?start=0
www.kzrider.com/forum/faq-wiki/618026-new-owner-things-to-know
1981 KZ750E2
www.kzrider.com/forum/11-projects/604901...z750e-project-thread
Please Log in or Create an account to join the conversation.
- 650ed
-
- Offline
- User
-
Registered
- Posts: 15337
- Thanks: 2833
Re: H4 conversion ?
18 Jan 2017 13:45 - 18 Jan 2017 13:46
I've used a number of different headlamps on my KZ650-C1 over the past 40 years including H4, stock, sealed Halogen, etc. I have found the Wagner H6024 Halogen sealed beam to be the most reliable lamp that fits directly into the stock shell and it provides very bright light, and no moisture or dirt can infiltrate the lens. Here's a link to where I have bought them -
www.summitracing.com/parts/WAG-H6024/
Here are the specs. Notice the wattage is nearly the same as the stock lamp. Ed
1977 KZ650-C1 Original Owner - Stock (with additional invisible FIAMM horn)
Last edit: 18 Jan 2017 13:46 by 650ed.
Please Log in or Create an account to join the conversation.
- kzdcw
-
Topic Author
- Offline
- User
-
Registered
- 77' KZ1000A
- Posts: 857
- Thanks: 13
Re: H4 conversion ?
18 Jan 2017 18:02 - 18 Jan 2017 18:04
Next time I'll entertain this sealed beam lamp, but for right now I ordered this one.
Thank You "All" for your Input
Thank You "All" for your Input

77' KZ1000A
Attachments:
Last edit: 18 Jan 2017 18:04 by kzdcw.
